Description
What Can This 3D Metal Detector Detect?
The Fusion Light is built for:
- Buried treasure chests
- Underground cavities
- Tunnels
- Tombs and subterranean chambers
- Hidden artefacts
It is not a simple coin finder. This is a deep treasure detector designed for serious underground exploration.
Operating Modes
The Fusion Light includes:
- 3D Ground Scan for underground imaging
- Magnetometer Mode for detecting ferrous metal anomalies
This dual system increases detection reliability when searching for buried structures or metallic objects.
Lightweight and Easy to Transport
One of the biggest advantages of the Fusion Light is portability.
- Weight: approx. 700 g
- Compact control unit design
- Approx. 12 hours operating time
- Fast 3-hour charging
This makes it one of the most practical professional 3D metal detector UK options for field use.
Technical Specifications
Control Unit
- Dimensions (H x W x D): 800 x 65 x 65 mm
- Weight: approx. 700 g
- Input voltage (max.): 19 V DC, 3.16 A
- Lithium-Ion baterry: 2600 mAh
- Operating time: approx. 12 h
- Charging Time: approx. 3 h
- Processor / Main CPU: Cortex M3, 32 MHz
- Processor / Slave CPU: Cortex M0, 24 MHz
- Sample rate: 1024 values / second
- Measurement resolution: 16 bit
- Operating temperature: –10°C – 60°C
- Storage temperature: –20°C – 70°C
- Waterproof: No
- Sensor technology / Coil technology: SCMI-15-D
- Air humidity: 5% – 75%
- Protection Type: IP40
Data Transmission
- Technology: Bluetooth 5.1
- Frequency: 2.402 – 2.480 GHz
- Maximum Transfer Rate: 1 Mbps
- Maximum Transmitting Power: +8 dBm
- Maximum Range: approx. 10 m
Computer Requirements
- Interface (data transmission): USB 2.0
- Free disk space: minimum 250 MB
- Working memory (RAM): 2 GB
- Display: 1920 x 1080
- Processor: 1.2 GHz
- Graphics card: 1 GB RAM, OpenGL 3.3
- Operating system: Windows 10
Who Is This 3D Ground Scanner Best For?
The Fusion Light is ideal if:
- You want to upgrade from a standard metal detector
- You are entering professional 3D ground scanning
- You need cavity detection capability
- You want a deep treasure detector UK without moving into ultra-high price ranges
It delivers real 3D imaging technology in a compact and more accessible package.
